Blade RF 88

El.En_Laser_BladeRF88
Family
Blade RF Sealed-Off (from 80 to 300W)

Rated power (W)

80

Wavelength (μm)

10.6 ± 0.4

Low Power RF Sealed Off Pulsed Laser with optimal laser beam parameters

Low Power RF Sealed Off Pulsed Laser with optimal laser beam parameters

RF 88 designed for low power laser applications. The Sealed-Off technology allows to maintain the laser parameters for a long time, guaranteeing high processing quality.  It is suitable where extreme precision and quality are needed. Compact size and easy to integrate into existing systems.

Materials

Food

Food

CO₂ lasers are a good choice for organic materials processing, because, like all carbon based materials, they absorb the 10.6 micrometers radiation of a CO₂ laser well. As a consequence, achieving laser organic material processing requires a very tiny amount of energy. Laser marking or bio-stimulation can be achieved in a new and cost-effective way. Through the years, El.En.'s laser sources found application all over the world in industrial processes as diverse as marking Parmesan cheese, fruit, or ham, cutting chestnuts or grafting plants.

Leather

Leather

Leather laser processing is widely used in the decoration and fashion industries. Cutting out intricate shapes, drilling hundreds of micro-holes or etching the most complicated arabesque is possible with El.En.'s laser sources. Using laser on leather is an extremely efficient operation: Since leather is a high-absorptive and low-conductive material, it takes small amounts of energy to get great results with low costs. Forget strong fixturing, metal dies or slow operations: The implementation of a laser source in your system will dramatically streamline your clean leather processing operations and boost your productivity rate!

Laser source technology offers several advantages:

    exclusive and incomparable decorative effects;

    low operational costs;

    inexistent environmental impact;

    work safety.

Paper / Label

Paper / Label

Paper and cardboard respond very well to the wavelength emitted by CO₂ laser beams. That makes paper digital converting extremely efficient. Being a non-contact process, laser finishing avoids the risk of deformation or distortion of the base material, always ensuring clean cuts and square edges, even with the most intricate designs. For those reasons, cutting and marking are the obvious applications of laser paper processing. Owing to their accuracy, El.En.'s CO₂ laser sources are also used in applications such as laser kiss cutting and laser micro-perforation, especially in the packaging and decorating.

Plastic film

Plastic film

CO₂ laser is a groundbreaking tool for plastic film processing applications. Packaging, coating, digital converting markets will all benefit from a CO₂ laser solution. Being a non-contact process, laser is perfect when you have to deal with a base material as delicate as plastic film. It is a non-contact process: You won't waste or deform the plastic film and you will get the most accurate results achievable today in manufacturing this plastic material. El.En. laser scanning heads make this process possible: They will steer the laser beam emitted by the CO₂ laser source, focusing it precisely where it is needed. By doing so, you will achieve processing such as kiss cutting, micro perforation or welding in applications such as easy opening packaging, micro-perforated films for bread and vegetables.

Processing

Laser Ablation

Laser Ablation

Laser ablation is indeed a versatile and precise technique for material removal from solid surfaces using laser energy. Laser ablation is highly precise, allowing for micron-level control over material removal. This precision is particularly advantageous in industries where selective material removal is crucial. The Minimal Heat Affected Zone (HAZ) is also a significat feature: laser ablation is a relatively low-heat process that minimizes the heat-affected zone, reducing the risk of thermal damage to the surrounding material. Materials like metals, polymers, ceramics, and composites can be laser ablated. This versatility makes it suitable for a broad spectrum of applications across different industries. In addition to material removal, laser ablation is widely used for surface cleaning. It can efficiently remove contaminants, oxides, or unwanted layers from surfaces, ensuring a clean substrate for subsequent processes.

Laser Cleaning

Laser Cleaning

Stripping large surfaces is a complex and expensive process. It normally requires the use of chemicals, considerable water and many hours of work. An environmentally friendly and flexible alternative to traditional paint stripping is laser stripping. Laser paint removal involves using laser to remove a layer of paint from the metal substrate on which it is applied. The main advantage is that the beam acts selectively on the paint without touching the metal underneath. The process is ideal for removing paint in a specific area, for example when particular points on the surface, covered with paint in a previous passage, need to be stripped for subsequent functionalization. Of all the paint stripping processes available, laser stripping is the most environmentally friendly: The beam instantly vaporizes the paint without producing any waste or residue. If you are looking for a precise, selective process to perfectly strip irregular or easily damaged surfaces, laser is the solution for you.

Laser Drilling

Laser Drilling

Imagine the possibility of making thousands of holes of any caliber in a short time. And without producing any chips and at exactly defined locations. That's exactly what a CO₂ laser source can do. Laser drilling is one of the most diffused laser applications, along with its sibling laser microperforation. Basically, the laser beam striking the surface of a plastic, metal or ceramic material, makes the base material evaporate. The holes resulting from this operation will have neat edges and won't need further processing operations. Furthermore, for drilling applications you can use the same laser sources you would use for cutting operations! El.En.'s laser sources have been engineered to work on metals, ceramic and plastic materials in machine tool, packaging, food, printing and decoration industries.

Laser Kiss-Cutting

Laser Kiss-Cutting

Laser kiss cutting is a special cutting technique. It is very useful in the paper converting and label production industries: Laser kiss cutting aims at cutting only the top layer of a two-layered sheet instead of cutting through a sheet of paper, as in traditional laser cutting. The production of sticky labels is one of the main fields of application of this processing technique. The advantages of laser kiss cutting are remarkable: Since it is a non-contact process, there won't be any die or blade getting glued to the adhesive layer, avoiding the costs of tool cleaning. Futhermore, laser kiss cutting applications do not require special equipment: A single CO₂ laser source can achieve both laser kiss cut and laser cut through processing. Laser kiss cut is great to be employed in the paper and label industries, where it can be easily integrated into the printing process, but is also perfect for the coating and film industries.

Specifications

Specifications


Rated power (W)

80

Effective peak power (W)

200

Power stability (long term)

±5%

Wavelength (μm)

10.6 ± 0.4

Polarization

linear (parallel to base)

Beam diameter (1/e² at the exit)

9.4 ± 0.5

Beam divergence (1/e² full angle) (mrad)

3.0 ± 0.3

Maximum pulse frequency (kHz)

50

Pulse width range (μs)

2 ÷ 1000

Maximum duty cycle

60%

Mode quality (M²)

< 1.2

Beam ellipticity

1.2 : 1

Optical pulse rise/fall time (μs)

< 50

Typical gas mix consumption (NL/year)

NA

Operating ambient temperature range (°C)

5 ÷ 35

Storage Temperature range (°C)

5 ÷ 50

Maximum humidity

Non condensing at inlet water temperature

Cooling


Heat load (W)

1500

Coolant temperature (°C)

23 ± 1

Water cooling input pressure (bar)

4

Water cooling flow rate (L/min)

5 ± 0.5

Dimension / Weight


Laser dimensions (LxWxH) (mm)

662x110x117

RF power supply dimensions

457x57x164

Safety shutter

NA

Laser Weight (kg)

9

RF power supply Weight (kg)

3.8

Electrical Power Requirements


Input voltage (Vᴰᶜ)

48 ± 1

Max current (A)

27

Peak Current (A)

32 for 3 ms max

Rated power (W)

80

Effective peak power (W)

200

Power stability (long term)

±5%

Wavelength (μm)

10.6 ± 0.4

Polarization

linear (parallel to base)

Beam diameter (1/e² at the exit)

9.4 ± 0.5

Beam divergence (1/e² full angle) (mrad)

3.0 ± 0.3

Maximum pulse frequency (kHz)

50

Pulse width range (μs)

2 ÷ 1000

Maximum duty cycle

60%

Mode quality (M²)

< 1.2

Beam ellipticity

1.2 : 1

Optical pulse rise/fall time (μs)

< 50

Typical gas mix consumption (NL/year)

NA

Operating ambient temperature range (°C)

5 ÷ 35

Storage Temperature range (°C)

5 ÷ 50

Maximum humidity

Non condensing at inlet water temperature

Laser dimensions (LxWxH) (mm)

662x110x117

RF power supply dimensions

457x57x164

Safety shutter

NA

Laser Weight (kg)

9

RF power supply Weight (kg)

3.8

Input voltage (Vᴰᶜ)

48 ± 1

Max current (A)

27

Peak Current (A)

32 for 3 ms max

Heat load (W)

1500

Coolant temperature (°C)

23 ± 1

Water cooling input pressure (bar)

4

Water cooling flow rate (L/min)

5 ± 0.5
